| Part Number | VCE(V) |
Ic(A)@ 100℃ |
Vcesat(V) @25℃ typ |
Eon(mJ) | Eoff(mJ) | Package | Status |
| MPF3L450R07XNF X1 | 650 | 450 | 1.42 | 7.3 | 31.6 | Flow 2 | MP |
| MPF3L400R10NNF | 1000 | 400 | 1.1 | 10.4 | 8 | Easy 3B | TP |
| MPFS400R08HBF | 750 | 400 | 1.34 | 5 | 20 | HP1 DC6 Pinfin | MP |
| MPFS600R08HBF | 750 | 600 | 1.4 | 8.4 | 56 | HP1 DC6 Pinfin | MP |
| MPFS600R08PBFH | 750 | 600 | 1.43 | 11.7 | 22.7 | HybridPACK Drive | MP |
| MPFS660R08PBFF | 750 | 660 | 1.14 | 15.6 | 17.4 | HybridPACK Drive Flat Baseplate | MP |
| MPFS820R08PBFH | 750 | 820 | 1.37 | 15.6 | 17.4 | HybridPACK Drive | MP |
| MPFS950R08PBFH | 750 | 950 | 1.48 | 15.8 | 39 | HybridPACK Drive | MP |
| MPFF100R12RM | 1200 | 100 | 1.6 | 2.2 | 4.6 | 34mm module | MP |
| MPFF150R12RM | 1200 | 150 | 2 | 14.2 | 8.8 | 34mm module | MP |
| MPFF200R12KM | 1200 | 200 | 1.43 | 3.2 | 12.6 | 62mm module | MP |
| MPFF200R12KNF | 1200 | 200 | 1.52 | 14 | 20 | 62mm module | MP |
| MPFF300R12KNF | 1200 | 300 | 1.51 | 25 | 29 | 62mm module | MP |
| MPFF300R12MNF | 1200 | 300 | 1.58 | 31 | 29 | EconoDUAL 3 | MP |
| MPFF450R12KBF | 1200 | 450 | 2.04 | 88.4 | 43.7 | 62mm module | MP |
| MPFF450R12KNF | 1200 | 450 | 1.59 | 74.7 | 45 | 62mm module | MP |
| MPFF450R12MBF | 1200 | 450 | 1.9 | 64.8 | 46.9 | EconoDUAL 3 | MP |
| MPFF450R12MNF | 1200 | 450 | 1.56 | 57 | 43 | EconoDUAL 3 | MP |
| MPFF600R12KNF | 1200 | 600 | 1.62 | 73 | 85 | 62mm module | MP |
| MPFF600R12MBF | 1200 | 600 | 1.65 | 118.4 | 79.2 | EconoDUAL 3 | MP |
| MPFF600R12MNF | 1200 | 600 | 1.47 | 68 | 48 | EconoDUAL 3 | MP |
| MPFH600R12MNF | 1200 | 600 | 2.2 | 178 | 86 | EconoDUAL 3 | MP |
| MPFF800R12KNF | 1200 | 800 | 1.7 | 106 | 112 | 62mm module | MP |
| MPFF900R12MNF | 1200 | 900 | 1.68 | 102 | 102 | EconoDUAL 3 | MP |
| MPFS50R17CNF | 1700 | 50 | 1.55 | 15.9 | 12.8 | EconoPIM2 | MP |
| MPFF50R17RNF | 1700 | 50 | 2.18 | 33 | 16 | 34mm module | MP |
| MPFF75R17RBF | 1700 | 75 | 2.18 | 36 | 18 | 34mm module | MP |
| MPFF100R17RBF | 1700 | 100 | 2.14 | 37.5 | 22.4 | 34mm module | MP |
| MPFF100R17KNF | 1700 | 100 | 2.14 | 37.5 | 22.4 | 34mm module | MP |
| MPFF150R17KBF | 1700 | 150 | 2.1 | 76 | 35 | 62mm module | MP |
| MPFF200R17KBF | 1700 | 200 | 2.1 | 90.9 | 53.8 | 62mm module | MP |
| MPFF300R17KBF | 1700 | 300 | 1.95 | 70.5 | 62.4 | 62mm module | MP |
| MPFF450R17MBF | 1700 | 450 | 2.14 | 98 | 92 | EconoDUAL 3 | MP |
| MPFF600R17MNF | 1700 | 600 | 2.1 | 161 | 251 | EconoDUAL3 | MP |
| MPFF800R17MNF | 1700 | 800 | 1.9 | 234 | 197 | EconoDUAL 3 | MP |
*
ES：Engineering Sample
TP：Test Production
PP：Pre-Production
MP：Mass-Production
